| L/MBP Commercial Series Compressor （208V-230V/60Hz） |
Technical Data
QD Series R290 Refrigeration Compressor（208V-230V/60Hz）
| 机型 Style | Model | Displ. (cm3) | 商业标称 POWER HP | Motor Type | Cooling | Capacity(W)54.4℃/ 130℉ Condensing Temp. 制冷量 | COP W/W 能效比 | Input Power (W) | Oil Charge | ||||||||||||
| 型号 | 气缸容积 | 电机类型 | 冷却方式 | 输入功率 | 注油量 | ||||||||||||||||
| -40℃ | -35℃ | -30℃ | -25℃ | -23.3℃ | -20℃ | -15℃ | -10℃ | -6.7℃ | -5℃ | 0℃ | -23.3℃ | -6.7℃ | -23.3℃ | -6.7℃ | |||||||
| DM | MBMQD30UHM | 3.30 | 1/6 | CSIR | F | 68 | 93.5 | 127.5 | 159.12 | 170 | 200.6 | 246.5 | 306 | 357 | 391 | 442 | 1.35 | 1.9 | 126 | 188 | 160 |
| MBMQD35UHM | 3.60 | 1/5 | CSIR | F | 76 | 104.5 | 142.5 | 177.84 | 190 | 216 | 250 | 290 | 320 | 437 | 494 | 1.35 | 1.9 | 141 | 168 | 160 | |
| DF | MBFQD43UHM | 4.36 | 1/4 | CSIR | F | 92 | 126.5 | 172.5 | 215.28 | 230 | 270 | 320 | 370 | 410 | 529 | 598 | 1.4 | 1.95 | 164 | 210 | 180 |
| MBFQD52UHM | 4.90 | 1/4+ | CSIR | F | 106 | 145.75 | 198.75 | 248.04 | 265 | 305 | 360 | 410 | 460 | 609.5 | 689 | 1.4 | 1.95 | 189 | 236 | 180 | |
| DL | MBLQD59UHM | 6.00 | 1/4+ | CSIR | F | 140 | 192.5 | 262.5 | 327.6 | 350 | 390 | 460 | 540 | 600 | 805 | 910 | 1.5 | 2 | 233 | 300 | 220 |
| MBLQD65UHM | 6.80 | 1/3 | CSIR | F | 158 | 217.25 | 296.25 | 369.72 | 395 | 425 | 460 | 585 | 650 | 908.5 | 1,027 | 1.5 | 2 | 263 | 325 | 220 | |
| MBLQD75UHM | 7.60 | 1/3 | CSIR | F | 176 | 242 | 330 | 411.84 | 440 | 470 | 510 | 645 | 720 | 1012 | 1,144 | 1.5 | 2 | 293 | 360 | 220 | |
| MBQQD91UHM | 9.30 | 3/8 | CSIR | F | 204 | 280.5 | 382.5 | 477.36 | 510 | 588 | 705 | 800 | 880 | 1173 | 1,326 | 1.45 | 2 | 352 | 440 | 250 | |
| MBQQD110UHM | 11.10 | 1/2 | CSIR | F | 244 | 335.5 | 457.5 | 570.96 | 610 | 700 | 688 | 960 | 1,060 | 1403 | 1,586 | 1.45 | 2 | 421 | 530 | 250 | |
| *MBQQD120UHW | 12.10 | 1/2+ | CSCR | F | 264 | 363 | 495 | 617.76 | 660 | 750 | 910 | 1,040 | 1,150 | 1518 | 1,716 | 1.5 | 2 | 440 | 575 | 250 | |
