| L/MBP Commercial Series Compressor（220V-240V/50Hz） |
| 机型 Style | Model | Displ. (cm3) | 商业标称 POWER HP | Motor Type | Cooling | Capacity(W)54.4℃/ 130℉ Condensing Temp. 制冷量 | COP W/W 能效比 | Input Power (W) | Oil Charge | ||||||||||||
| 型号 | 气缸容积 | 电机类型 | 冷却方式 | 输入功率 | 注油量 | ||||||||||||||||
| -40℃ | -35℃ | -30℃ | -25℃ | -23.3℃ | -20℃ | -15℃ | -10℃ | -6.7℃ | -5℃ | 0℃ | -23.3℃ | -6.7℃ | -23.3℃ | -6.7℃ | |||||||
| MAMQD30UHP | 3.30 | 1/8 | RSIR | F | 58 | 79.75 | 108.75 | 135.72 | 145 | 171.1 | 210.25 | 261 | 305 | 333.5 | 377 | 1.3 | 1.85 | 112 | 165 | 160 | |
| MAMQD35UHP | 3.60 | 1/6 | RSIR | F | 66 | 90.75 | 123.75 | 154.44 | 165 | 194.7 | 239.25 | 297 | 347 | 379.5 | 429 | 1.3 | 1.85 | 127 | 187 | 160 | |
| MAMQD43UHP | 4.50 | 1/5 | RSIR | F | 84 | 115.5 | 157.5 | 196.56 | 210 | 247.8 | 304.5 | 378 | 441 | 483 | 546 | 1.35 | 1.9 | 156 | 232 | 160 | |
| MAMQD52UHP | 5.30 | 1/5 | RSIR | F | 98 | 134.75 | 183.75 | 229.32 | 245 | 289.1 | 355.25 | 441 | 515 | 563.5 | 637 | 1.35 | 1.9 | 181 | 271 | 160 | |
| DF | MAFQD43UHP | 4.90 | 1/5 | RSIR | F | 92 | 126.5 | 172.5 | 215.28 | 230 | 271.4 | 333.5 | 414 | 483 | 529 | 598 | 1.4 | 1.95 | 164 | 248 | 180 |
| MAFQD52UHP | 5.50 | 1/5 | RSIR | F | 104 | 143 | 195 | 243.36 | 260 | 306.8 | 377 | 468 | 546 | 598 | 676 | 1.4 | 1.95 | 186 | 280 | 180 | |
| MAFQD59UHP | 6.20 | 1/5 | RSIR | F | 120 | 165 | 225 | 280.8 | 300 | 354 | 435 | 540 | 630 | 690 | 780 | 1.45 | 2 | 207 | 315 | 180 | |
| MAFQD65UHP | 6.60 | 1/4 | RSIR | F | 130 | 178.75 | 243.75 | 304.2 | 325 | 383.5 | 471.25 | 585 | 683 | 747.5 | 845 | 1.45 | 2 | 224 | 341 | 180 | |
| MAFQD75UHC | 7.20 | 1/4+ | RSCR | F | 140 | 192.5 | 262.5 | 327.6 | 350 | 413 | 507.5 | 630 | 735 | 805 | 910 | 1.53 | 2.05 | 229 | 359 | 180 | |
| MAFQD75UHC | 7.60 | 1/4+ | RSCR | F | 150 | 206.25 | 281.25 | 351 | 375 | 442.5 | 543.75 | 675 | 788 | 862.5 | 975 | 1.5 | 2.03 | 250 | 388 | 180 | |
| DL | MALQD75UHP | 8.30 | 1/4+ | RSIR | F | 160 | 220 | 300 | 374.4 | 400 | 472 | 580 | 720 | 840 | 920 | 1,040 | 1.45 | 2 | 276 | 420 | 220 |
| MALQD91UHM | 9.30 | 3/8 | CSIR | F | 180 | 247.5 | 337.5 | 421.2 | 450 | 531 | 652.5 | 810 | 945 | 1035 | 1,170 | 1.45 | 2 | 310 | 473 | 220 | |
| MALQD110UHW | 10.00 | 3/8+ | CSCR | F | 192 | 264 | 360 | 449.28 | 480 | 566.4 | 696 | 864 | 1,008 | 1104 | 1,248 | 1.6 | 2.05 | 300 | 492 | 220 | |
| MALQD110UHW | 11.10 | 3/8+ | CSCR | F | 212 | 291.5 | 397.5 | 496.08 | 530 | 625.4 | 768.5 | 954 | 1,113 | 1219 | 1,378 | 1.5 | 2 | 353 | 557 | 220 | |
| DQ | MAQQD91UHM | 9.30 | 3/8 | CSIR | F | 180 | 247.5 | 337.5 | 421.2 | 450 | 531 | 652.5 | 810 | 945 | 1035 | 1,170 | 1.45 | 1.95 | 310 | 485 | 250 |
| MAQQD110UHM | 11.10 | 3/8+ | CSIR | F | 212 | 291.5 | 397.5 | 496.08 | 530 | 625.4 | 768.5 | 954 | 1,113 | 1219 | 1,378 | 1.45 | 1.95 | 366 | 571 | 250 | |
| MAQQD120UHW | 12.8 | 3/5 | CSCR | F | 244 | 335.5 | 457.5 | 570.96 | 610 | 719.8 | 884.5 | 1,098 | 1,281 | 1403 | 1,586 | 1.55 | 2 | 394 | 641 | 250 | |
| MAQQD142UHW | 14.2 | 1/2 | CSCR | F | 272 | 374 | 510 | 636.48 | 680 | 802.4 | 986 | 1,224 | 1,428 | 1564 | 1,768 | 1.55 | 2 | 439 | 714 | 250 | |
| MAQQD158UHW | 15.4 | 1/2+ | CSCR | F | 296 | 407 | 555 | 692.64 | 740 | 873.2 | 1073 | 1,332 | 1,554 | 1702 | 1,924 | 1.55 | 2 | 477 | 777 | 250 | |
