L/M/HBP Commercial Series Compressor 208V-230V/60Hz-Hangzhou Comptek Compressor Manufacturing CoLtd

L/M/HBP Commercial Series Compressor 208V-230V/60Hz

Application:

Water cooler,beverage cooler,ice maker,beer dispenser, vending machine,food exhibitor, wine cooler,dehumidifier,vpright cabinet,cake cabinet,professional kitchen, chest freezer,

refrigerated island, medical cooler etc.

Advantages

1) Environmentally friendly

2) Smaller compressor dimensions or smaller displacements possible

3) Low noise level, innovative compressor technology

4) Compact start equipment

5) Low energy consumption

6) High thermal working conditions

7) High product quality

8) Wide voltage range

DL R600a_副本.jpg

QD Series R600a Refrigeration Compressor（208V-230V/60Hz）

机型 Style	Model	Displ. (cm3)	POWER HP	Motor Type	Cooling	Capacity(W)54.4℃/ 130℉ Condensing Temp.														COP W/W 能效比			Input Power (W)			Oil Charge
机型 Style	DM					一35℃	一30℃	一25℃	一23.3℃	一20℃	一15℃	一10℃	一6.7℃	一5℃	0℃	5℃	7.2℃	10℃	15℃	一23.3℃	一6.7℃	7.2℃	一23.3℃	一6.7℃	7.2℃
DW	TBWQD30YHP	3.0	1/12	RSIR	S	25	35	50	58	70	85	115	130	140	170	205	230	255	345	1.15	1.7	2.8	50	78	82	140
	TBWQD35YHP	3.5	1/12	RSIR	S	30	40	60	66	80	100	135	155	160	200	240	265	295	400	1.15	1.7	2.8	57	91	95	140
	TBWQD43YHP	4.3	1/10	RSIR	S	35	52	72	82	98	123	168	188	197	246	295	330	365	493	1.15	1.7	2.8	71	111	118	140
	TBWQD52YHP	5.2	1/8	RSIR	S	42	60	81	92	110	138	186	210	225	280	335	370	412	560	1.18	1.71	2.82	78	123	132	140
DM	TBFDM65YHP	6.5	1/6	RSIR	S	55	80	110	126	150	190	246	285	300	375	450	500	550	750	1.31	1.76	2.86	96	162	175	150
DM	TBFDM75YHP	7.5	1/6	RSIR	S	60	90	122	140	170	212	285	325	345	430	520	580	640	870	1.32	1.77	2.87	106	184	202	150
DF	TBFDF75YHP	7.5	1/6	RSIR	S	60	90	122	140	170	212	285	325	345	430	520	580	640	870	1.32	1.77	2.87	106	184	202	180
	TBFDF85YHP	8.5	1/5	RSIR	S	70	100	140	158	187	235	320	365	383	480	580	645	710	970	1.36	1.85	2.9	116	197	223	180
	TBFDF91YHP	9.1	1/5	RSIR	S	73	107	148	165	200	250	335	385	405	510	610	680	750	1020	1.37	1.86	2.91	121	207	234	180
DL	TBLQD103YHP	10.3	1/5+	RSIR	S/F	80	120	160	185	225	280	390	445	470	585	700	780	860	1170	1.41	2	3.03	131	223	260	220
	TBLQD110YHP	11.1	1/5+	RSIR	S/F	85	125	170	195	235	290	400	460	485	610	730	810	890	1220	1.42	2	3.03	137	230	267	220
	TBLQD118YHY	11.8	1/4	CSIR	F	90	130	180	205	245	310	425	480	510	640	765	850	940	1280	1.43	2.05	3.05	143	234	279	220
	TBLQD128YHY	12.8	1/4	CSIR	F	100	140	195	220	265	330	450	520	545	680	820	900	1000	1350	1.44	2.06	3.06	153	252	294	220
DQ	TBQQD142YHY	14.2	1/3	CSIR	F	115	170	235	260	320	400	540	620	650	825	980	1080	1200	1630	1.42	1.96	2.96	183	316	365	250
DQ	TBQQD158YHY	15.3	1/3	CSIR	F	130	190	260	290	350	440	610	690	730	910	1100	1200	1300	1800	1.41	1.95	2.95	206	354	407	250
